Colorful Cuttlefish and their Creative Camouflage

By Jocelyn Brown, John Lee, & Janine Mistrick

Despite their name, cuttlefish are not fish or even vertebrates. They are mollusks and more specifically cephalopods, being closely related to squid and octopus. They derive their name from the cuttlebone, which is a hard, internal shell primarily composed of aragonite and utilized for buoyancy control. Belonging to the order Sepiida, cuttlefish possess the general cephalopod body plan with the head and mantle forming a single unit from which eight arms and two sucker-covered tentacles are attached.



Cuttlefish range across much of the Old World from the Western and South Pacific to the coasts of Africa to the Mediterranean and North Seas. They are mostly warm water species, living in shallow habitats near the coast. These animals generally range in size from 15 to 25 cm while the largest species can grow to 50 cm. The life expectancy of cuttlefish is from one to two years in the wild (Norman 2000; Reid 2006; Roper 1984).

A cuttlefish uses a variety of colors and patterns to camouflage with a leaf below it on the seafloor.

A cuttlefish uses a variety of colors and patterns to camouflage with a leaf below it on the seafloor.

Cuttlefish are most famous for their ability to change their skin color in mere seconds. Even more so than other closely-related cephalopods, cuttlefish use color and pattern changes to communicate with other cuttlefish, to camouflage themselves when in danger, and to frighten off potential predators (Norman 2000; Reid 2006; Roper 1984; Shohet 2006).

When cuttlefish are camouflaging with their environment, substrate contrast and particle size are the two main factors that cuttlefish use to adjust their body pattern to display a wide array of patterns from uniform/stipple, to mottle, to disruptive (Barbosa et al 2008 – Cuttlefish Camouflage).

Examples of three general camouflage patterns expressed by cuttlefish are shown: uniform/stipple, mottle, and disruptive.

Examples of three general camouflage patterns expressed by cuttlefish are shown: uniform/stipple, mottle, and disruptive.

Uniform/stipple and mottle body coloration are two camouflage patterns commonly used by cuttlefish. These two patterns can be generally grouped under the term “background matching” (Buresch 2011).

Uniform coloration involves minimal or no contrast variation in skin color. Uniform coloration is used when cuttlefish camouflage with open, uniform sand or uniformly colored rocks or when they are hiding in the shadows. Stipple patterns are often considered to be a subset of uniform patterning. Stipple patterning is characterized by a uniform distribution of small, rounded spots. This pattern represents a transition phase from uniform to mottle patterns.

A cuttlefish uses a uniform/stipple pattern in a similar shade of beige to blend in with the sand in its environment.

A cuttlefish uses a uniform/stipple pattern in a similar shade of beige to blend in with the sand in its environment.

Mottle coloration is defined as small-to-moderate-scale light and dark splotches distributed fairly evenly and repeatedly across the body. Low-to-moderate contrast between the light and dark patches characterizes this pattern (Hanlon et al 2009).

The pattern cuttlefish choose to display generally matches the pattern and contrast of the substrate it is attempting to camouflage with. Often, a general background match is chosen and the cuttlefish will change its body color and pattern to generally resemble the contrast, texture, intensity, and color of the substrate but the exact pattern will not match the immediate background (Hanlon et al 2009).

Cuttlefish: Chameleons of the Sea

The more contrast present in the background, the higher the intensity of the camouflage pattern the cuttlefish will display (Hanlon et al 2009). High-contrast substrates often evoke another type of camouflage patterning called disruptive patterning.

Disruptive patterning is a type of camouflage which is characterized by high-contrast light and dark patches in a random orientation that might also disrupt the organisms shape and orientation. Examples of this can be seen everywhere, even in human behavior, in which soldiers wear camouflage in order to hide themselves from enemies.

Stark contrast is seen in this cuttlefish as it uses a disruptive color pattern to break up its outline as viewed by overhead predators.

Stark contrast is seen in this cuttlefish as it uses a disruptive color pattern to break up its outline as viewed by overhead predators.

The cuttlefish however, are experts in disruptive patterning and are able to make themselves appear invisible to both predators and prey in a hundredth of a second! They are able to make such instantaneous changes in their appearance by using their neurally controlled chromatophore system in their skin. Chromatophores contain their pigments in a cytoelastic sac. Cuttlefish are able to change color by making the cytoelastic sac bigger or smaller and by distorting the cytoelastic sac’s shape. (Cloney 1968)

Cuttlefish use disruptive components typically for blending in with larger particles and objects, rather that fine gravel. Additionally, this camouflage mechanism is used when the edges of the background are clear and discrete. Other factors that signal for disruptive patterning are the visual depth of the object, as well as brightness of the background. There continues to be a lot of stipulation on the mechanisms of disruptive patterning in cuttlefish due to its complexity and nearly instantaneous transformation.

A cuttlefish uses a uniform/stipple pattern in a similar shade of beige to blend in with the sand in its environment.

A cuttlefish uses a uniform/stipple pattern in a similar shade of beige to blend in with the sand in its environment.

The cuttlefish has a highly evolved system of skin coloration that it uses for camouflage and display. Being able to blend into a variety of environments, a camouflaged cuttlefish is often indistinguishable from animals of the same species. You could say that cuttlefish are truly nature’s masters of disguise!

Can Cuttlefish camouflage in a living room? – Richard Hammond’s Miracles of Nature – BBC One

MEDIA REFERENCES

Barbosa, A. et al. Cuttlefish camouflage: The effects of substrate contrast and size in evoking uniform, mottle or disruptive body patterns. Vision Research 48, 1242–1253 (2008).

Can Cuttlefish Camouflage in a Living Room? – Richard Hammond’s Miracles of Nature – BBC One. YouTube. BBC, 23 Nov. 2012. Web. <https://www.youtube.com/watch?v=pgDE2DOICuc&gt;.

Cuttlefish: Chameleons of the Sea. YouTube. Discovery, 11 May 2010. Web. <https://www.youtube.com/watch?v=WqMNjUp6UeA&gt;.

Dachalan. “Cuttlefish.” Flickr.com. Flickr, a Yahoo Company, 9 April 2007. Web. 15 April 2015.

Dachalan. “Cuttlefish.” Flickr.com. Flickr, a Yahoo Company, 10 April 2008. Web. 15 April 2015.

Simmons, Charlene N. “Cuttlefish.” Photograph. Flickr.com. Flickr, a Yahoo Company, 3 June 2014. Web. 15 April 2015.

Stiefel, Klaus. “Cuttlefish.” Flickr.com. Flickr, a Yahoo Company, 5 November 2011. Web. 15 April 2015.

World’s Deadliest – “Sudden Death” Cuttlefish. YouTube. NatGeoWild, 1 Apr. 2013. Web. <https://www.youtube.com/watch?v=E-zodF-XrSE&gt;.

TEXT REFERENCES

Barbosa, A. et al. Cuttlefish camouflage: The effects of substrate contrast and size in evoking uniform, mottle or disruptive body patterns. Vision Research 48, 1242–1253 (2008).

Barbosa, A., Litman, L. & Hanlon, R. T. Changeable cuttlefish camouflage is influenced by horizontal and vertical aspects of the visual background. J Comp Physiol A 194, 405–413 (2008).

Buresch, K. C. et al. The use of background matching vs. masquerade for camouflage in cuttlefish Sepia officinalis. Vision Research 51, 2362–2368 (2011).

Cloney, R. A., and E. Florey. “Ultrastructure of cephalopod chromatophore organs.” Zeitschrift fur Zellforschung und mikroskopische Anatomie 89.2 (1968): 250-280.

Hanlon, R. T. et al. Cephalopod dynamic camouflage: bridging the continuum between background matching and disruptive coloration. Philosophical Transactions of the Royal Society of London B: Biological Sciences 364, 429–437 (2009).

Kelman, E. J., Baddeley, R. J., Shohet, A. J. & Osorio, D. Perception of visual texture and the expression of disruptive camouflage by the cuttlefish, Sepia officinalis. Proc. R. Soc. B 274, 1369–1375 (2007).

Norman, M. D. Cephalopods: A World Guide. N.p.: Conch, 2000.

Reid, A., P. Jereb, and C. F. E. Roper. Cephalopods of the World, An Annotated and Illustrated Catalogue of Species Known to Date. Volume 1. Chambered Nautiluses and Sepioids (Nautilidae, Sepiidae, Sepiolidae, Sepiadariidae, Idiosepiidae, and Spirulidae. 4th ed. Vol. 1. Rome: FAO, 2005.

Roper, C. F. E., M. J. Sweeney, and C. E. Nauen. Cephalopods of the World. Vol. 3. Rome: FAO, 1984.

Shohet, Adam, Roland Baddeley, John Anderson, and Daniel Osorio. “Cuttlefish camouflage: a quantitative study of patterning.” Biological Journal of the Linnean Society, 92.2 (2006): 335-345.

Advertisements

Aliens of the Sea: Creatures from the Deep

By Laura McAndrews & Sarah Schlicher

In the ocean, for every ten meters you travel down the pressure increases by one atmosphere. When humans experience high pressure, their lungs begin to compress and the body changes how blood is distributed in the body. We can only survive as long as the pressure inside our bodies is enough to balance the pressure outside. However, there are a number of creatures that have adapted specifically to live in high pressure, and the resulting physical appearances can be strange.

In 2013 the Blobfish, Psychrolutes marcidus, was voted the World’s Ugliest Animal. Normally experiencing pressures many times that of sea level, when brought to the surface its low density flesh becomes deformed, and the result is its sad, gelatinous face. The Blobfish typically lives off the coast of Australia and Tasmania at depths of 600 to 1200 meters, where it floats above the sea floor. It is able to do so due to its primarily gelatinous flesh, which lacks muscle and allows the fish to withstand high pressures and move more efficiently over the bottom of the sea. Though the Blobfish has never been observed feeding, since it floats across the sea floor and lacks the muscle to chase prey, it is thought to eat matter that can float into its mouth, including crustaceans, sea urchins, and mollusks. Unfortunately, however, despite being inedible, the Blobfish is often caught accidentally by deep-sea trawlers, and is quickly becoming endangered.

Another creature notorious for its strange appearance is the Goblin Shark, Mitsukurina owstoni. Pinkish-grey with a flabby body and soft skin, it also inhabits the deep sea with a depth range of 40 to 1,200 meters. Just like the Blob Fish, the Goblin Shark has a density close to seawater, and waits to ambushes its prey rather than actively pursuing. Unlike the Blobfish, however, it feeds midwater rather than at the bottom of the sea. The flabby and elongated snout is thought to be used to detect prey, and its protrusible jaw, for which it is well known, is used to suck in its catch. For a while scientists actually believed there were a number of different species of Goblin Shark, since in preserved specimens the jaw would stiffen into place, and most had been preserved with jaws protruded to differing points, changing the appearance of the entire head. This was likely due in part to the relatively small amount known about the species, since they are rarely seen or caught, and also therefore used for little. However, scientists believe that the Goblin Shark could be more common than originally thought, since they seem to be widely distributed, with specimens caught near Japan, New Zealand, southern Africa, and other locations around the world.

Last but not least is the Vampire Squid, Vampyroteuthis infernalis. This creature is known to have the largest eyes to body ratio of any animal. Like the Blobfish, the vampire squid has a gelatinous body that is capable of drawing its eight, web-connected arms up and over itself to form a protective web. Protruding off of the eight legs are fleshy spins called cirri, adding to its strange appearance.  One of the many eerie characteristics of this creature is its ability to bioluminescence through its light-producing organs called photophores. The Vampire Squid has the ability to “turn on or off” the light and change intensity to create patterns to confuse predators and prey.  Unlike the Blobfish and the Goblin Shark, the Vampire Squid travels fast, up to two times its 6 inch body length per second. Although not much is known about its feeding habits, it is believed to have a diet of prawns, copepods, cnidarians, and other small invertebrates. The vampire squid’s ivory beak-like jaw, located within the webbing, has been found in the stomach of seals, whales, and large fishes. This squid is found throughout the worlds’ oceans, but mostly tropic and temperate areas at depths of 90 to 900 meters. Scientists believe that the Vampire Squid prefer to be in temperatures of 2 to 4 degrees Celsius.
